Bicicleta Mondraker ZENDIT XR 2027

Cuadro

Zendit Stealth Air full Carbon, Updated Zero Suspension System, 165mm travel, Forward Geometry, internal battery, Boost 12x148mm rear axle, UDH, tapered head tube, one-piece Monoblock upper link, HHG internal cable routing, MAX capacity sealed bearings, oversize 15mm axles, exclusive plastic motor covers.

Tallas

S: 380mm / M: 410mm / ML: 435mm / L: 460mm / XL: 490mm

Amortiguador

Fox Float X2 Factory Kashima 205x65mm. 2-positions lever compresion (Open/Firm), low-speed compression, low-speed rebound, air preload. Trunnion top mount, 30x8mm bottom bushings.

Ajuste del amortiguador

CS 30 compression, 1,1 Bleed, RS40 rebound, Rezi B40, LML, Long MCU, 0 volume spacers.

Horquilla

Fox Podium 29 Float GRIP X2 Factory Kashima, 170mm, tapered steerer tube, Boost 20x110mm thru axle, 44mm offset. High and low-speed compression, high and low-speed rebound, air preload.

Dirección

Acros custom ZS56/ZS56, 1-1/8", 1.5" head tube, Internal cable routing, sealing plugs, with blocklock: S, M / without blocklock: ML, L, XL.

Potencia

Onoff S9 30mm 0º, Full CNC, 31.8mm barbore.

Manillar

Onoff S9 1.0 Carbon, rise: 25mm, width: 800mm, 8º backsweep, 5º upsweep, 31.8mm barbore. L and XL size: 38mm rise.

Puños

Onoff Desert Pro, CNC lock-on, 135mm. L and XL: Thicker size.

Tija

RockShox Reverb AXS, diameter 31.6mm, w/AXS Pod Controller Rocker Paddle. S size: 398.2x125mm, M size: 448.2x150mm,ML size: 498.2x175mm, L size: 548.2x200mm, XL size:548.2x200mm.

Sillin

Ergon SM10 E-Mountain Black.

Freno delantero

Sram Maven Ultimate, 18 millimeter 4-piston caliper, HS2 220mm IS 6 bolts one-piece rotor, steel-backed metal sintered pads

Freno trasero

Sram Maven Ultimate, 18 millimeter 4-piston caliper, HS2 200mm IS 6 bolts one-piece rotor, steel-backed metal sintered pads

Manetas de freno

Sram Maven Ultimate , Carbon lever, SwingLink and lever pivot bearings, tools-free reach adjust

Llantas

DT Swiss, Carbon

Radios

DT Hybrid II Straightpull, w/DT ProLock Squorx ProHead aluminum nipples, Three-cross (1:1) pattern.

Buje delantero

DT Swiss 350, 20x110mm Boost, Disc IS (6-bolt).

Buje trasero

DT Swiss 350, 12x148mm Boost, Disc IS (6-bolt), Sram XD Steel (SRAM) freehub body, 72T Ratchet DEG DF System.

Neumático delantero

Maxxis Assegai 29x2.5WT, tubeless ready, 3C Maxx Grip compound, DD protection, 120x2TPI, folding bead

Neumático trasero

Maxxis Minion DHR II 27.5x2.5 WT, tubeless ready, 3C MaxxTerra compound, DD protection, 120x2TPI, folding bead

Bielas

e*thirteen Helix Race Carbon e*spec. All sizes: 155mm

Platos

Sram XX Eagle 36T T-Type, 104BCD, steel, CL55

Pedales

N/A

Cadena

Sram GX Eagle T-Type, 12s, w/Powerlock

Cambio - trasero

Sram X0 Eagle AXS T-Type, 12s

Mandos - pulsadores de cambio

Sram Eagle AXS Pod Controller Rocker Paddle w/discrete clamp, 12s

Piñones

Sram XS 1275, 10-52T, T-Type, 12s

Patilla de cambio

Not included - UDH compatible

Peso sin pedales

23.1 Kg

Display

Avinox DP100 Display / Avinox BC100 Wireless Controller (L&R)

Motor

Avinox Drive Unit

Bateria

Avinox 800Wh Battery / Avinox 12A Charger
